JAYMAC BAR DECOILING AND STRAIGHTENING MACHINE

JAYMAC BAR DECOILING AND STRAIGHTENING MACHINE

800000 INR/Set

Get a Price/Quote

Product Details:

Motor Power 15 Kilowatt (kW)
Product Type Bar de-coiling and straightening machine
General Use Decoiling and straightening of rebars
Material Steel
Weight (kg) 950 Kilograms (kg)
Computerized Yes
Automatic Yes
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

JAYMAC BAR DECOILING AND STRAIGHTENING MACHINE Price And Quantity

Price Range 800000.00 - 1000000.00 INR/Set
Minimum Order Quantity 1 Set
Price 800000 INR/Set

JAYMAC BAR DECOILING AND STRAIGHTENING MACHINE Product Specifications

Weight (kg) 950 Kilograms (kg)
Feature Decoiling and straightening of rebars
Voltage 415 Volt (v)
Motor Power 15 Kilowatt (kW)
Product Type Bar de-coiling and straightening machine
General Use Decoiling and straightening of rebars
Cooling System Hydraulic Oil Cooling
Automatic Yes
Color Red
Control System PLC Control
Material Steel
Method Hydraulic Pressure
Computerized Yes
Warranty 1
Dimension (L*W*H) 2800 X 760 X 1150 mm Millimeter (mm)

JAYMAC BAR DECOILING AND STRAIGHTENING MACHINE Trade Information

FOB Port Kolkata
Supply Ability 10 Set Per Week
Main Export Market(s) Asia Australia Eastern Europe Western Europe Middle East Africa
Main Domestic Market All India
Certifications CE & ISO 9001

Product Description

Bar Decoiling Straightening Machine is an innovative design for straightening round steel hot and cold rolled rebar ribbed steel and thread screw steel

Specifications

Model ST14

Cutting Length Error 2 cm

Shearing Motor Power 75 kW 10 HP

Straightening and Drive Motor Power 15 kW 20 HP

Dimension 2800 x 760 x 1150 mm

Net weight Approx 950 kg

Technical Data

Model ST 14

Round Bar 4 14 mm Reinforce Steel Bar 6 12 mm

Wire transportation speed 55mmin

Wire design length can be increased 450mm9999m

Cutting length error 2cm

Shearing motor power 75 kw 10 HP

Straightening Drive motor power 15 kw 20 HP

Dimension 2800 x 760 x 1150 mm

Net Weight approx 950 kg

6 Mtr Stand Included
