Jaypee Automatic Batching Plant (Reversible Drum)

Jaypee Automatic Batching Plant (Reversible Drum)

1999999.00 INR/Piece

Get a Price/Quote

Product Details:

Product Type ABP(reversible drum)
General Use Industrial, Construction
Material Steel
Capacity 0.56 CuM at 120 Sec per batch m3/hr
Weight (kg) 70600 Kilograms (kg)
Computerized Yes
Automatic Yes
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Jaypee Automatic Batching Plant (Reversible Drum) Price And Quantity

Price 1999999.00 INR/Piece
Minimum Order Quantity 1 Piece

Jaypee Automatic Batching Plant (Reversible Drum) Product Specifications

Warranty 1
Product Type ABP(reversible drum)
Feature weight detection by load cell and printer facility available
Voltage 15 Horsepower (HP)
General Use Industrial, Construction
Cooling System Other
Dimension (L*W*H) 800 * 300 * 420 Centimeter (cm)
Method Hydraulic Pressure
Material Steel
Capacity 0.56 CuM at 120 Sec per batch m3/hr
Weight (kg) 70600 Kilograms (kg)
Computerized Yes
Control System Manual
Automatic Yes
Color Gray

Jaypee Automatic Batching Plant (Reversible Drum) Trade Information

Payment Terms Cash Against Delivery (CAD) Cash on Delivery (COD) Cash Advance (CA) Cash in Advance (CID)
Supply Ability 10 Piece Per Month
Delivery Time 10 Days
Sample Policy Contact us for information regarding our sample policy
Main Domestic Market All India
Certifications CE and TUV

Product Description

The Reversible Drum Automatic Batching Plant has a mixer output of 16 to 18 cum

MODEL	Automatic Batching Plant 18 (REVERSIBLE DRUM)
MIXER TYPE	REVERSIBLE DRUM
MIXER OUTPUT	18 CUM
BATCH CAPACITY	0.56 CUM
BATCH TIME	120 SEC per BATCH
POWER TRANSMISSION	15 HP GEARED MOTOR
CONTROL SYSTEM	FULLY AUTOMATIC OR MANUAL
DRY CAPACITY	1400 ltrs
DRUM RPM	20
FRAME & CHASSIS	ALL RIGID STEEL STRUCTURE
WEIGHING CONVEYOR	TO FEED AGGREGATES FROM BIN TO MIXER, POWERED BY 7.5 HP MOTOR, BELT SIZE 700MM WIDTH, 4PLY 8MM THICK WITH I TYPE LOAD CELL
GATE OPENING	PNEUMATIC CONTROL
WEIGHING SYSTEM	DIGITAL LOAD CELL BASED WEIGHING SYSTEM
COMPRESSOR	POWERED BY 3 HP MOTOR
SCREW CONVEYOR	220 MM DIA, 7 MTR LENGTH, POWERED BY 7.5 HP MOTOR 1000 KG
FEEDING HOPPER FOR CEMENT	500 KG
CEMENT RECHARGE HOPPER	CAPACITY 250 KG, LOADCELL
AGGREGATE STORAGE SYSTEM	4 BINS EACH OF VOLUME 3 CUM WITH SHUTTER VIBRATOR
GATE OPENING	PNEUMATIC CONTROL, POWERED BY 3 HP COMPRESSOR
WATER DOZING	TANK CAPACITY 120 LTR
CHEMICAL DOZING	TANK CAPACITY 5 LTR
TOTAL POWER CONSUMPTION	32.5 KW
CONTROL PANEL	PLC BASED BACKUP AND RESET CONTROL PANEL
