Jaypee Reverse Drum Mixer

600000.00 INR/Set

Get a Price/Quote

Product Details:

Product Type Reverse Drum Mixer
General Use Construction
Capacity 18 m3/hr
Weight (kg) 70600 Kilograms (kg)
Computerized Yes
Automatic Yes
Control System PLC Control
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Price And Quantity

Minimum Order Quantity 1 Set
Price 600000.00 INR/Set

Product Specifications

Capacity 18 m3/hr
Feature weight detection by load cell and printer facility available
General Use Construction
Product Type Reverse Drum Mixer
Computerized Yes
Control System PLC Control
Automatic Yes
Warranty 1
Dimension(L*W*H) 481.6 * 200 * 310 Centimeter (cm)
Weight (kg) 70600 Kilograms (kg)
Cooling System Hydraulic Oil Cooling

Trade Information

Payment Terms Cash Against Delivery (CAD), Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID)
Supply Ability 10 Set Per Month
Delivery Time Days
Main Domestic Market All India
Certifications CE & TUV

Product Description

REVERSE DRUM CONCRETE MIXER MACHINE

Jaypee Reversible drum Concrete Mixer has become the most reliable for quality output and maintenance free operation. One of the most widely used machine tools is the Automatic Batching Plant -18 (Reversible Drum), They are the typical reversible type concrete mixer where concreting is done using a revolving drum. Designed to deliver sturdy construction a reversible drum mixer is a well engineered piece of construction machinery for carrying mixing mortar to place where it is to be poured. It also gives enough time to the workers to mix the composition before the concrete hardens.

Product details

Batch Capacity	0.3 - 0.5 CuM
Hopper Capacity	850, 1100, 1400 Kg
Machine Output	12 - 18 CuM per hr
Power	10, 15 HP (7.5 KW and 11 KW resp) Elec. Motor
Brand	Jaypee
Dimension	4816 X 2000 X 3100 mm
Type of the drum mixer	Reverse Drum Mixer
Weight	1830, 2280, 2650, 2950 kg
Condition	New

Specifications:

Hopper Capacity (Dry): 850-1100-1400 kg
Batch Capacity (Wet): 0.3-0.5-0.56 CuM
Machine Output / Hour: 12-18 CuM per hr
Power: 10-15 HP (7.5 - 11kW) Elec. Motor or 16 HP diesel Engine
Weighing Type: 1 Bin & 3 Bin
Dimensions (L * W * H): 4816 * 2000 * 3100 mm
Weight (Approx): 1830 - 2950 kg
